SYNONYM TR 1
rear shock:Fox Factory Float DPS 2pos remote lockout, push-to-unlock, Evol LV Trunnion 165x42.5
fork: Fox Factory 34 Step Cast Float FIT4, 120mm travel, 2pos remote lockout w/ Open Mode Adj, push-to-unlock, 15x110mm Boost, 1.5 tapered steerer tube, 44 offset
headset:FSA NO.42/47/ACB
stem:Synonym Trail 31.8 (S: 50, M, L & XL: 60mm), angle +5°
handlebar:NS Licence Carbon Mini Rise Lite 31.8, 760mm, 15mm rise
grips:NS Hold Fast supersoft
seatpost:Fox Transfer Performance Elite S: 120mm, M, L, XL: 150mm
saddle:Octane One Crit, Ti-Alloy rails
front brake:Sram Level TL, 180mm
rear brake:Sram Level TL, 160mm
levers:Sram Level TL
rims:NS Enigma Lite 29", 32h, tubeless ready
spokes:Straight Pull Spokes
front hub: NS Rotary Straight Pull 15 Boost 15x110 disc (sealed bearings)
rear hub: NS Rotary Straight Pull Cassette 148x12mm Boost (sealed bearings)
tires front / rear:Maxxis Recon 2.4WT EXO/TR / Maxxis Ikon 2.35 EXO/TR
crankset:Truvativ X1 Carbon DUB 170mm 34t (XL size 175mm)
bottom bracket:Sram DUB Press Fit BB92
chain:Sram, 12 spd
derailleurs:Sram X01 Eagle type 3 12spd
shifters:Sram GX Eagle, 12spd
cassette:Sram XG-1275, 10-50t 12 speed
weight (kg):11.8 (M size, tubeless setup)
Specifications subject to change without notice. Actual colours and design may vary slightly from the images on the website.
| Synonym TR 1 | S | M | L | XL | |
| Wheel | size | 29" | |||
| Fork | travel | 120 | 120 | 120 | 120 |
| Reach | mm | 436 | 466 | 491 | 511 |
| in | 17.2 | 18.3 | 19.3 | 20.1 | |
| FC | mm | 732 | 766 | 796 | 824 |
| in | 28.8 | 30.2 | 31.3 | 32.4 | |
| Standover | mm | 754 | 753 | 753 | 754 |
| in | 29.7 | 29.6 | 29.6 | 29.7 | |
| Stack | mm | 590 | 599 | 614 | 632 |
| in | 23.2 | 23.6 | 24.2 | 24.9 | |
| Effective TT | mm | 582 | 615 | 644 | 667 |
| in | 22.9 | 24.2 | 25.4 | 26.3 | |
| Actual TT | mm | 548 | 580 | 611 | 640 |
| in | 21.6 | 22.8 | 24.1 | 25.2 | |
| Seat tube | mm | 410 | 440 | 490 | 540 |
| in | 16.1 | 17.3 | 19.3 | 21.3 | |
| Chain stays | mm | 438 | 438 | 438 | 438 |
| in | 17.2 | 17.2 | 17.2 | 17.2 | |
| BB rise | mm | -38 | -38 | -38 | -38 |
| in | -1.5 | -1.5 | -1.5 | -1.5 | |
| BB height | mm | 326 | 326 | 326 | 326 |
| Headtube | angle | 66.0 | 66.0 | 66.0 | 66.0 |
| ST angle | effective | 76.0 | 76.0 | 76.0 | 76.0 |
| Wheelbase | mm | 1167 | 1201 | 1232 | 1260 |
| in | 45.9 | 47.3 | 48.5 | 49.6 | |
